NS36IR Side Rod Assembly: The Foundation of Structural Integrity
The NS36IR Drifter Rock Drill operates at 1,630 blows per minute (BPM), subjecting its chassis to intense vibration and continuous compressive forces. To combat this, the Side Rod Assembly is engineered from high-tensile alloy steel, allowing it to withstand extreme torque loads while ensuring peak performance and a long cycle life. Ultimately, the machine’s structural integrity and resistance to misalignment depend almost entirely on the precise assembly of these rods and the exact application of their fastening torque.
For workshop managers and technical engineers, treating the assembly procedure as a safety-critical function is non-negotiable. Loose fasteners resulting from vibration are a precursor to catastrophic mechanical failure and require proactive checking during routine maintenance.
Critical Torque Setting: 125 Nm
The side rod nuts are the primary structural fasteners that hold the entire drifter body together, compressing the backhead, cylinder, and front housing. These nuts must be tightened evenly to a critical OEM torque setting of 125 Nm (92.195 ft/lbs).
This specific torque value is calculated to maintain the required structural compression, preventing vibration from separating or damaging the primary components. Failure to achieve or maintain this torque setting can lead to the loosening of the structure, resulting in internal misalignment, rapid wear, and premature breakdown. Workshop checklists must include a spot check of these nuts as part of the periodic inspections.
NS36IR Side Rod Assembly and Dismantling Procedure
The systematic procedure for dismantling and reassembly ensures the structural components are handled correctly, protecting delicate internal interfaces.
Dismantling Key Steps:
The process begins with cleaning the exterior, followed by the removal of the side rod nuts and the fronthead locking plate. The side rods are removed by unscrewing the lock nuts as the rod is withdrawn. This sequence ensures components are removed systematically from the front, safeguarding the major sub-units like the rotation drive assembly and the valve box.
Assembly Key Steps:
Before commencing reassembly, every component must be washed in a solvent, dried thoroughly, and lubricated with rock drill oil. Crucially, components that require pressing such as bushings and cylinder washer liners must never be driven with a hammer.
The final steps of the NS36IR Side Rod Assembly are:
1. Insert the side rods through the lugs in the backhead and down the machine. First fit the Side Rod Lock Nut over the threads against the front cover.
2. Then fit the correct shank adaptor into the machine and attach the fronthead locking plate with the Dome nuts on the outside.
3. Tighten the nuts evenly to the critical torque of 125 Nm (92.195 ft/lbs).
After final assembly, a function test must always be carried out, connecting a restricted air line to check the correct functioning of the piston and valve, and ensuring the rotation motor runs freely in both directions.
As a specialist OEM manufacturer, NASA Engineering SA provides all the necessary components, including genuine side rods, nuts, and washers, manufactured with the exact tolerance required for the 125 Nm compression. For detailed technical diagrams and reference numbers, visit our website Home – NASA Engineering South Africa
Protect your valuable assets by choosing OEM quality and adhering to expert procedural guidelines. You can view our full range of manufactured components on our Products and Solutions page: Product Catalogue – NASA Engineering South Africa. For direct guidance on workshop training and torque auditing, please contact our technical team at NASA Engineering SA (Pty) Ltd: Contact Us – HQ – NASA Engineering South Africa.
